set dir "c:\temple nod\"

set window off
set display mode 1280, 720, 32, 1
Sync on
Sync Rate 60
autocam off
hide mouse
Global BloomShaderEffectID as integer = 22
Global QuadShaderEffectID as integer = 23

Global FullScreenShaderPlane as integer = 5000
Global FullscreenShaderImage as integer = 2
Global BackdropColor as dword
BackdropColor = rgb(40,40,40)  // the camera 0 backdrop is not usedm this variable is for setting the bloom camera backdrop to the same value as camera 0.

Global NrOfbjects as integer = 100
Reload Display Pointer   // Needed for fullscreen shaders to work properly

Color Backdrop BackdropColor
InitFullscreenShaders()


      make camera 2
      set camera to image 2,3,512,512
      color backdrop 2,rgb(255,255,255)
      Make Dynamic Cube Map 1,512

load effect "fx/cubicshadowmapping.fx",1,0


load object "ast/char/boy2.x", 1
      Apply Cube Map To Object 1,2,1
set object effect 1, 1
load image "ast/char/boy.png", 1
load image "ast/char/boy_nrm.png", 2
texture object 1, 0, 1
texture object 1, 1, 2
set object normals 1
set object texture 1, 0, 1, 1
position object 1, 0, -13, 0
scale object 1, 300, 300, 300
loop object 1
set object speed 1, 5



make object plain 2, 900, 900
position object 2, 0, -20, 0
xrotate object 2, 90
load image "ast/lev/rockwall2.png", 3
load image "ast/lev/rockwall2_nrm.png", 4
texture object 2, 0, 3
texture object 2, 1, 4
scale object texture 2, 7, 17
set object effect 2, 1
rem Apply Cube Map To Object 2,2,1


load object "ast/char/point.3ds", 3

scale listener 0.5
vec=make vector4(1) REM for light shader


do

position object 3, camera position x(), camera position y(), camera position z()
yrotate object 3, camera angle y() : move object 3, -100

set camera to follow object position x(1), object position y(1), object position z(1), wrapvalue( camera angle y() + mousemovex() / 2.0 ), 42, 42, 7, 0
if keystate(17) then point object 1, object position x(3), 0, object position z(3) : move object 1, -1 : xrotate object 1, 0
if keystate(31) then point object 1, object position x(3), 0, object position z(3) : move object 1, 1 : xrotate object 1, 0

if keystate(30) then rot#=object angle y(1)-1 : yrotate object 1, rot#
if keystate(32) then rot#=object angle y(1)+1 : yrotate object 1, rot#

print object angle y(1)
REM shadow shader
REM set light position
set vector4 1,camera position x(), camera position y(), camera position z() ,0
set effect constant vector 1,"LightPosition",1
   `Render shadiow map
      set effect technique 1,"DepthMap"
      Render Dynamic Cube Map 1,2, 50, 10, 0
   `Main Scene
      set effect technique 1,"ShadowMapping"
      sync mask 2^0
REM shadow shader

UpdateFullScreenShaders()
sync
loop



Function InitFullscreenShaders()

        Local TempVector as integer = 5000

        // Make the "bloom camera" and set the backdrop color
        Make Camera 1
        Color Backdrop 1, BackdropColor

        // load the bloom shader as a camera effect and set the "bloom camera" to draw on "FullscreenShaderImage"
        Load Camera Effect  "fx/postbloom.fx",BloomShaderEffectID,0
        Set Camera Effect  1,BloomShaderEffectID,FullscreenShaderImage

        // FullScreenShaderPlane is the "canvas" where the camera image is drawn and later displayed.
        Make Object Plain FullScreenShaderPlane,2,2,1
        Set Object Radius FullScreenShaderPlane,-1

        // Load and apply the quad shader to the "canvas" plane. The quad shader aligns the "canvas" plane to point at the camera and stretches it across the screen.
        Load Effect "fx/quad.fx",QuadShaderEffectID,0
        Set Object Effect FullScreenShaderPlane,QuadShaderEffectID

        // We need to set the "ViewSize" variable in the bloom shader so it knows how large our screen is.
        null = Make Vector4(TempVector)
        Set Vector4 TempVector, Screen Width(), Screen Height(),0,0
        Set Camera Effect Constant Vector BloomShaderEffectID,"ViewSize",TempVector
        null = Delete Vector4(TempVector)

        // Texture the quad (canvas) plane with the image from the bloom camera.
        Texture Object FullScreenShaderPlane,0, FullscreenShaderImage



EndFunction

Function UpdateFullScreenShaders()

        // Before "sync" the bloom camera is placed at the correct position to view the scene.
    position camera 1,camera position x(0),camera position y(0),camera position z(0)
        rotate camera 1,camera angle x(0),camera angle y(0),camera angle z(0)

        // Show all objects to the bloom camera. and hide the "canvas" plane so the bloom camera will not see it
        ShowObjectsForFullscreenShader()
        hide object FullScreenShaderPlane

        // Sync the bloom camera and hide all objects again, performance degrades if both cameras has to draw all objects.
        sync camera 1
    HideObjectsForFullscreenShader()
    //  show the "canvas plane".
        show object FullScreenShaderPlane

        // Tell the "Sync" command to only sync camera 0 from here on.
        sync mask %001

EndFunction

Function HideObjectsForFullscreenShader()

        // All objects in the scene has to be hidden after the scene has been drawn to the bloom camera.
        // Performance degrades if objects are drawn to both cameras.
        For i = 1 To NrOfbjects
                IF Object Exist(i)
                        Hide Object  i
                Endif
        Next

endfunction

Function ShowObjectsForFullscreenShader()

        // Show all objects (to the bloom camera only)
        For i = 1 To NrOfbjects
                If Object Exist(i)
                        Show Object i
                Endif
        Next

Endfunction

Sync on
Sync Rate 60
autocam off
hide mouse

      make camera 1
      set camera to image 1,3,256,256
      color backdrop 1,rgb(255,255,255)
      Make Dynamic Cube Map 1,256

load effect "fx/cubicshadowmapping.fx",1,0

load image "c:/dumbt.png", 1
load image "c:/dumbt_NRM.png", 2
make object sphere 1, 20
Apply Cube Map To Object 1,2,1
set object effect 1, 1
position object 1, 0, -13, 0
scale object 1, 300, 300, 300
texture object 1, 0, 1
texture object 1, 1, 2


make object plain 2, 900, 900
position object 2, 0, -20, 0
xrotate object 2, 90
scale object texture 2, 900, 900
set object effect 2, 1
Apply Cube Map To Object 2,2,1
texture object 2, 0, 1
texture object 2, 1, 2

vec=make vector4(1) REM for light shader


do
print "arrow keys to move"
control camera using arrowkeys 0, 1, 3
REM shadow shader
REM set light position
 set vector4 1,40, 20, 0,0
            set effect constant vector 1,"LightPosition",1

   `Render shadiow map
      set effect technique 1,"DepthMap"
      Render Dynamic Cube Map 1,1,40, 20, 0

   `Main Scene
      set effect technique 1,"ShadowMapping"
      sync mask 2^0
REM shadow shader


sync
loop

      make camera 1 ` dummy camera - not used
      make camera 2
      set camera to image 2,3,256,256
      color backdrop 2,rgb(255,255,255)
      Make Dynamic Cube Map 1,256

      make camera 1 ` dummy camera - not used
      make camera 5
      set camera to image 5,3,256,256
      color backdrop 5,rgb(255,255,255)
      Make Dynamic Cube Map 1,256

set window off
set display mode 1280, 720, 32, 1
Sync on
Sync Rate 60
autocam off
hide mouse
Global BloomShaderEffectID as integer = 22
Global QuadShaderEffectID as integer = 23

Global FullScreenShaderPlane as integer = 5000
Global FullscreenShaderImage as integer = 2
Global BackdropColor as dword
BackdropColor = rgb(40,40,40)  // the camera 0 backdrop is not usedm this variable is for setting the bloom camera backdrop to the same value as camera 0.

Global NrOfbjects as integer = 100
Reload Display Pointer   // Needed for fullscreen shaders to work properly

Color Backdrop BackdropColor
InitFullscreenShaders()

      make camera 2
      set camera to image 2,3,256,256
      Make Dynamic Cube Map 1,256
      color backdrop 2,rgb(255,255,255)

load effect "fx/cubicshadowmapping.fx",1,0


load object "ast/char/boy2.x", 1
      Apply Cube Map To Object 1,2,1
set object effect 1, 1
load image "ast/char/boy.png", 1
load image "ast/char/boy_nrm.png", 2
texture object 1, 0, 1
texture object 1, 1, 2
set object normals 1
set object texture 1, 0, 1, 1
position object 1, 0, -13, 0
scale object 1, 300, 300, 300
loop object 1, 20, 38
set object speed 1, 40



make object plain 2, 900, 900
position object 2, 0, -20, 0
xrotate object 2, 90
load image "ast/lev/rockwall2.png", 3
load image "ast/lev/rockwall2_nrm.png", 4
texture object 2, 0, 3
texture object 2, 1, 4
scale object texture 2, 7, 17
set object effect 2, 1
rem Apply Cube Map To Object 2,2,1


load object "ast/char/point.3ds", 3

scale listener 0.5
vec=make vector4(1) REM for light shader


do

position object 3, camera position x(), camera position y(), camera position z()
yrotate object 3, camera angle y() : move object 3, -100

set camera to follow object position x(1), object position y(1), object position z(1), wrapvalue( camera angle y() + mousemovex() / 2.0 ), 42, 42+mousemovey(), 7, 0 : point camera object position x(1), object position y(1)+30, object position z(1)
if keystate(17) then point object 1, object position x(3), 0, object position z(3) : move object 1, -5 : xrotate object 1, 0
if keystate(31) then point object 1, object position x(3), 0, object position z(3) : move object 1, 5 : xrotate object 1, 0

rem if mousemovey()<20 and mousemovey()>-20 then mousemovey()=camangview#
rem print camangview#

if keystate(30) then rot#=object angle y(1)-1 : yrotate object 1, rot#
if keystate(32) then rot#=object angle y(1)+1 : yrotate object 1, rot#


REM shadow shader
REM set light position
 set vector4 1,40, 20, 0, 1 // correction by GG (probably not needed)
set effect constant vector 1,"LightPosition",1
   `Render shadiow map
      set effect technique 1,"DepthMap"
      Render Dynamic Cube Map 1,2, 50, 10, 0
   `Main Scene
      set effect technique 1,"ShadowMapping"
      sync mask 2^0
REM shadow shader

UpdateFullScreenShaders()
sync
loop



Function InitFullscreenShaders()

        Local TempVector as integer = 5000

        // Make the "bloom camera" and set the backdrop color
        Make Camera 1
        Color Backdrop 1, BackdropColor

        // load the bloom shader as a camera effect and set the "bloom camera" to draw on "FullscreenShaderImage"
        Load Camera Effect  "fx/postbloom.fx",BloomShaderEffectID,0
        Set Camera Effect  1,BloomShaderEffectID,FullscreenShaderImage

        // FullScreenShaderPlane is the "canvas" where the camera image is drawn and later displayed.
        Make Object Plain FullScreenShaderPlane,2,2,1
        Set Object Radius FullScreenShaderPlane,-1

        // Load and apply the quad shader to the "canvas" plane. The quad shader aligns the "canvas" plane to point at the camera and stretches it across the screen.
        Load Effect "fx/quad.fx",QuadShaderEffectID,0
        Set Object Effect FullScreenShaderPlane,QuadShaderEffectID

        // We need to set the "ViewSize" variable in the bloom shader so it knows how large our screen is.
        null = Make Vector4(TempVector)
        Set Vector4 TempVector, Screen Width(), Screen Height(),0,0
        Set Camera Effect Constant Vector BloomShaderEffectID,"ViewSize",TempVector
        null = Delete Vector4(TempVector)

        // Texture the quad (canvas) plane with the image from the bloom camera.
        Texture Object FullScreenShaderPlane,0, FullscreenShaderImage



EndFunction

Function UpdateFullScreenShaders()

        // Before "sync" the bloom camera is placed at the correct position to view the scene.
    position camera 1,camera position x(0),camera position y(0),camera position z(0)
        rotate camera 1,camera angle x(0),camera angle y(0),camera angle z(0)

        // Show all objects to the bloom camera. and hide the "canvas" plane so the bloom camera will not see it
        ShowObjectsForFullscreenShader()
        hide object FullScreenShaderPlane

        // Sync the bloom camera and hide all objects again, performance degrades if both cameras has to draw all objects.
        sync camera 1
    HideObjectsForFullscreenShader()
    //  show the "canvas plane".
        show object FullScreenShaderPlane

        // Tell the "Sync" command to only sync camera 0 from here on.
        sync mask %001

EndFunction

Function HideObjectsForFullscreenShader()

        // All objects in the scene has to be hidden after the scene has been drawn to the bloom camera.
        // Performance degrades if objects are drawn to both cameras.
        For i = 1 To NrOfbjects
                IF Object Exist(i)
                        Hide Object  i
                Endif
        Next

endfunction

Function ShowObjectsForFullscreenShader()

        // Show all objects (to the bloom camera only)
        For i = 1 To NrOfbjects
                If Object Exist(i)
                        Show Object i
                Endif
        Next

Endfunction

load image "ast/char/boy.png", 1
load image "ast/char/boy_nrm.png", 2
texture object 1, 0, 1
texture object 1, 1, 2

Global FullscreenShaderImage as integer = 2

        // Texture the quad (canvas) plane with the image from the bloom camera.
        Texture Object FullScreenShaderPlane,0, FullscreenShaderImage

REM shadow shader
REM set light position
 set vector4 1, lightX#, lightY#, lightZ#, 1 // correction by GG (probably not needed)
set effect constant vector ShadowMapShaderEffectID,"LightPosition",1
   `Render shadow map
      set effect technique ShadowMapShaderEffectID,"DepthMap"
      hide object FullScreenShaderPlane ` this seems to be essential here - not obvious why ***
      Render Dynamic Cube Map CubeMapID,ShadowMapCameraID, lightX#, lightY#, lightZ#
   `Main Scene
      set effect technique ShadowMapShaderEffectID,"ShadowMapping"
`      sync mask 2^0 ` out of place - but why should this matter? ***
REM shadow shader

`set window off
`set display mode 1280, 720, 32, 1
set display mode desktop width(), desktop height(), 32, 1
Reload Display Pointer   // Needed for fullscreen shaders to work properly

Sync on
Sync Rate 60
sync

autocam off
hide mouse
Global BloomShaderEffectID as integer = 22
Global QuadShaderEffectID as integer = 23

Global FullScreenShaderPlane as integer = 5000
Global FullscreenShaderImage as integer = 2 ` I have no idea why this doesn't cause a conflict with object 1's nmap???
Global BackdropColor as dword
BackdropColor = rgb(40,40,40)  // the camera 0 backdrop is not used this variable is for setting the bloom camera backdrop to the same value as camera 0.

Global NrOfbjects as integer = 100

// globals added by GG to simplify debugging
global lightX# = 30.0
global lightY# = 30.0 ` raised to make ground shadows easier to see - hopefully
global lightZ# = 0.0
global BloomCameraID = 2
global ShadowMapCameraID = 1
global ShadowMapShaderEffectID = 24
global CubeMapID = 1
global LightObjectID = 4

Color Backdrop BackdropColor
InitFullscreenShaders()

      make camera ShadowMapCameraID
`      set camera to image 2,3,256,256 ` not needed ?
      Make Dynamic Cube Map CubeMapID,256
      color backdrop ShadowMapCameraID,rgb(255,255,255)

load effect "fx/cubicshadowmapping.fx",ShadowMapShaderEffectID,0


load object "ast/char/boy2.x", 1
      Apply Cube Map To Object 1,2,CubeMapID
set object effect 1, ShadowMapShaderEffectID
load image "ast/char/boy.png", 1
load image "ast/char/boy_nrm.png", 2
texture object 1, 0, 1
texture object 1, 1, 2
set object normals 1
set object texture 1, 0, 1, 1
position object 1, 0, -13, 0
scale object 1, 300, 300, 300
loop object 1, 20, 38
set object speed 1, 40



make object plain 2, 900, 900
position object 2, 0, -20, 0
xrotate object 2, 90
load image "ast/lev/rockwall2.png", 3
load image "ast/lev/rockwall2_nrm.png", 4
texture object 2, 0, 3
texture object 2, 1, 4
scale object texture 2, 7, 17
set object effect 2, ShadowMapShaderEffectID
Apply Cube Map To Object 2,2,CubeMapID

` marker object to denote light (and cube map camera) position
make object sphere LightObjectID, 3
color object LightObjectID, rgb(255,255,255)
set object light LightObjectID, 0
position object LightObjectID, lightX#, lightY#, lightZ#

`load object "ast/char/point.3ds", 3 ` not needed ? what is it and what does it do?

`scale listener 0.5 ` not needed

vec=make vector4(1) REM for light shader


do

`position object 3, camera position x(), camera position y(), camera position z()
`yrotate object 3, camera angle y() : move object 3, -100

set camera to follow object position x(1), object position y(1), object position z(1), wrapvalue( camera angle y() + mousemovex() / 2.0 ), 42, 42+mousemovey(), 7, 0 : point camera object position x(1), object position y(1)+30, object position z(1)
`if keystate(17) then point object 1, object position x(3), 0, object position z(3) : move object 1, -5 : xrotate object 1, 0
`if keystate(31) then point object 1, object position x(3), 0, object position z(3) : move object 1, 5 : xrotate object 1, 0

rem if mousemovey()<20 and mousemovey()>-20 then mousemovey()=camangview#
rem print camangview#

if keystate(30) then rot#=object angle y(1)-1 : yrotate object 1, rot#
if keystate(32) then rot#=object angle y(1)+1 : yrotate object 1, rot#


REM shadow shader
REM set light position
 set vector4 1, lightX#, lightY#, lightZ#, 1 // correction by GG (probably not needed)
set effect constant vector ShadowMapShaderEffectID,"LightPosition",1
   `Render shadow map
      set effect technique ShadowMapShaderEffectID,"DepthMap"
      hide object FullScreenShaderPlane ` this seems to be essential here - not obvious why
      Render Dynamic Cube Map CubeMapID,ShadowMapCameraID, lightX#, lightY#, lightZ#
   `Main Scene
      set effect technique ShadowMapShaderEffectID,"ShadowMapping"
`      sync mask 2^0 ` out of place - but why should this matter????
REM shadow shader

UpdateFullScreenShaders()
sync
loop



Function InitFullscreenShaders()

        Local TempVector as integer = 5000

        // Make the "bloom camera" and set the backdrop color
        Make Camera BloomCameraID
        Color Backdrop BloomCameraID, BackdropColor

        // load the bloom shader as a camera effect and set the "bloom camera" to draw on "FullscreenShaderImage"
        Load Camera Effect  "fx/postbloom.fx",BloomShaderEffectID,0
        Set Camera Effect  BloomCameraID,BloomShaderEffectID,FullscreenShaderImage

        // FullScreenShaderPlane is the "canvas" where the camera image is drawn and later displayed.
        Make Object Plain FullScreenShaderPlane,2,2,1
        Set Object Radius FullScreenShaderPlane,-1

        // Load and apply the quad shader to the "canvas" plane. The quad shader aligns the "canvas" plane to point at the camera and stretches it across the screen.
        Load Effect "fx/quad.fx",QuadShaderEffectID,0
        Set Object Effect FullScreenShaderPlane,QuadShaderEffectID

        // We need to set the "ViewSize" variable in the bloom shader so it knows how large our screen is.
        null = Make Vector4(TempVector)
`        Set Vector4 TempVector, Screen Width(), Screen Height(),0,0
        Set Vector4 TempVector, desktop Width(), desktop Height(),0,0
        Set Camera Effect Constant Vector BloomShaderEffectID,"ViewSize",TempVector

        // ideally we also need to specify the InvViewSize variable for the quad shader (added by GG)
        set vector4 TempVector, 1.0/desktop width(), 1.0/desktop height(), 0, 0
        set effect constant vector QuadShaderEffectID, "InvViewSize", TempVector

        null = Delete Vector4(TempVector)

        // Texture the quad (canvas) plane with the image from the bloom camera.
        Texture Object FullScreenShaderPlane,0, FullscreenShaderImage



EndFunction

Function UpdateFullScreenShaders()

        // Before "sync" the bloom camera is placed at the correct position to view the scene.
    position camera BloomCameraID,camera position x(0),camera position y(0),camera position z(0)
        rotate camera BloomCameraID,camera angle x(0),camera angle y(0),camera angle z(0)

        // Show all objects to the bloom camera. and hide the "canvas" plane so the bloom camera will not see it
        ShowObjectsForFullscreenShader()
        hide object FullScreenShaderPlane

        // Sync the bloom camera and hide all objects again, performance degrades if both cameras has to draw all objects.
        sync camera BloomCameraID
    HideObjectsForFullscreenShader()
    //  show the "canvas plane".
        show object FullScreenShaderPlane

        // Tell the "Sync" command to only sync camera 0 from here on.
        sync mask %001

EndFunction

Function HideObjectsForFullscreenShader()

        // All objects in the scene has to be hidden after the scene has been drawn to the bloom camera.
        // Performance degrades if objects are drawn to both cameras.
        For i = 1 To NrOfbjects
                IF Object Exist(i)
                        Hide Object  i
                Endif
        Next

endfunction

Function ShowObjectsForFullscreenShader()

        // Show all objects (to the bloom camera only)
        For i = 1 To NrOfbjects
                If Object Exist(i)
                        Show Object i
                Endif
        Next

Endfunction

Global FullscreenShaderImage as integer = 2

sync mask 2^BloomCameraID
sync

sync camera BloomCameraID

REM shadow shader
REM set light position
 set vector4 1, lightX#, lightY#, lightZ#, 1 // correction by GG (probably not needed)
set effect constant vector ShadowMapShaderEffectID,"LightPosition",1
   `Render shadow map
      set effect technique ShadowMapShaderEffectID,"DepthMap"
      hide object FullScreenShaderPlane ` this seems to be essential here - not obvious why
      sync mask 2^ShadowMapCameraID
      ShowObjectsForFullscreenShader() ` essential after first loop!!
      Render Dynamic Cube Map CubeMapID,ShadowMapCameraID, lightX#, lightY#, lightZ#
   `Main Scene
      set effect technique ShadowMapShaderEffectID,"ShadowMapping"
`      sync mask 2^0 ` out of place - but why should this matter????
REM shadow shader
