Sprite Animation won't animate in main loop

Author

Message

Artformer

14

Years of Service

User Offline

Joined: 23rd Aug 2010

Location: Scotland

Posted: 13th Jul 2016 18:00

Link

Hello,
Excuse me bothering you with this, but I seem to be missing something in my code.. I'm rebuilding a game I made in DBPro in AGK2, and I'm learning the basics of animation. I've created an atlas image of 8 rows of 5 animation images, which is two separate movements of one character, each being 5 * 4 images = 20 frames each. I can't seem to get any animation whatsoever within the main loop.. I've included the files.. can anyone see what I've done wrong please? This is my own artwork, each frame is 100 * 100
Thanks for your help.
Regards
Howard

Attachments

Login to view attachments

Back to top

Profile PM Email

blink0k

Moderator

11

Years of Service

User Offline

Joined: 22nd Feb 2013

Location: the land of oz

Posted: 14th Jul 2016 00:25 Edited at: 14th Jul 2016 00:26

Link

It seems to work ok for me. Nice animation, lots of character

Back to top

Profile PM

Artformer

14

Years of Service

User Offline

Joined: 23rd Aug 2010

Location: Scotland

Posted: 14th Jul 2016 00:44

Link

The spritesheet has an upward and a downward moving character, and I'd like to have full control of each movement. At the moment, its just playing through 20 frames of each in a continuous loop of 40 frames.
I cannot get PlaySprite to work within the main loop either. I have modified the coding here, but still can't get it to work....

Attachments

Login to view attachments

Back to top

Profile PM Email

blink0k

Moderator

11

Years of Service

User Offline

Joined: 22nd Feb 2013

Location: the land of oz

Posted: 14th Jul 2016 01:16 Edited at: 14th Jul 2016 01:37

Link

try this;

// Project: Sprite Sheet Test
// Created: 2016-07-13

// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "Sprite Sheet Test" )
SetWindowSize( 1024, 768, 0 )
adjustScreenPercentage()
// set display properties
SetVirtualResolution( 1024, 768 )
SetOrientationAllowed( 1, 1, 1, 1 )

global lastkey as integer
global spr as integer
global img as integer
global stfrm as integer
global endfrm as integer
spr=CreateSprite(0)
img1=LoadImage("HatrixDNUPspritesheet.png") //500*800

setspritepositionbyoffset(spr,50,50)
SetSpriteImage ( spr, img1 )
SetSpriteAnimation( spr, 800/8, 500/5, 40 )
setspritesize(spr,-1,100)
SetSpriteOffset(spr,getspritewidth(spr)/2.0,getspriteheight(spr))
SetSpritePosition(spr,100,100)

stfrm=1
endfrm=20
lastkey=83
curfrm#=stfrm

//
do
	GOSUB GetKeyPress
	print("Frame="+str(curfrm#))
	SetSpriteFrame(spr, trunc(curfrm#))
	inc curfrm#, 0.5
	if curfrm# > endfrm
		curfrm#=stfrm
	endif
//	PlaySprite( spr)
    Sync()
loop

GetKeyPress:
	IF GetRawKeyPressed( 83 )=1  // "W" UP
		stfrm=21
		curfrm#=stfrm
		endfrm=40
	ENDIF
	IF GetRawKeyPressed( 87 )=1 //"S" DOWN
		stfrm=1
		curfrm#=stfrm
		endfrm=20
	ENDIF

RETURN

function adjustScreenPercentage()
	w as float
	h as float
	SetDisplayAspect(w/h)
	endfunction

+ Code Snippet


// Project: Sprite Sheet Test
// Created: 2016-07-13

// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "Sprite Sheet Test" )
SetWindowSize( 1024, 768, 0 )
adjustScreenPercentage()
// set display properties
SetVirtualResolution( 1024, 768 )
SetOrientationAllowed( 1, 1, 1, 1 )

global lastkey as integer
global spr as integer
global img as integer
global stfrm as integer
global endfrm as integer
spr=CreateSprite(0)
img1=LoadImage("HatrixDNUPspritesheet.png") //500*800


setspritepositionbyoffset(spr,50,50)
SetSpriteImage ( spr, img1 )
SetSpriteAnimation( spr, 800/8, 500/5, 40 )
setspritesize(spr,-1,100)
SetSpriteOffset(spr,getspritewidth(spr)/2.0,getspriteheight(spr))
SetSpritePosition(spr,100,100)

stfrm=1
endfrm=20
lastkey=83
curfrm#=stfrm

//
do
	GOSUB GetKeyPress
	print("Frame="+str(curfrm#))
	SetSpriteFrame(spr, trunc(curfrm#))
	inc curfrm#, 0.5
	if curfrm# > endfrm
		curfrm#=stfrm
	endif
//	PlaySprite( spr)
    Sync()
loop


GetKeyPress:
	IF GetRawKeyPressed( 83 )=1  // "W" UP
		stfrm=21
		curfrm#=stfrm
		endfrm=40
	ENDIF
	IF GetRawKeyPressed( 87 )=1 //"S" DOWN
		stfrm=1
		curfrm#=stfrm
		endfrm=20
	ENDIF

RETURN

function adjustScreenPercentage()
	w as float
	h as float
	SetDisplayAspect(w/h)
	endfunction

Back to top

Profile PM

Artformer

14

Years of Service

User Offline

Joined: 23rd Aug 2010

Location: Scotland

Posted: 14th Jul 2016 10:27

Link

Good job BlinkOk! Apart from sprites image reversed for up/down key.. (just reversed the key assignment.. probably my error). So now I'm trying to understand what you've done here. curfrm# is a real number not Integer, which I guess is so it will track fractions of a frame, which is rounded up/down by the TRUNC function. But you are not using PLAYSPRITE, so what prints the sprite frames? Is there a limitation in the use of PLAYSPRITE that needs to be fixed, forcing people to ignore it? The animation is running way too fast, so I assume a timer has to be implemented? How can I create the same game speed on multiple platforms? Thanks for the help!

Back to top

Profile PM Email

blink0k

Moderator

11

Years of Service

User Offline

Joined: 22nd Feb 2013

Location: the land of oz

Posted: 14th Jul 2016 12:13

Link

curfrm# is a float so you can control the speed of the animation (Change .05 to say .02 and it will slow down)
SetSpriteFrame() is what displays the frame of the animation
if you want a consistent frame rate you could use elapsed time to select the frame

before you were executing playsprite() every frame so it was always setting the animation to the first frame. you need a system where by playsprite is executed ONLY when the state changes

Back to top

Profile PM

Funnell7

13

Years of Service

User Offline

Joined: 8th Sep 2011

Location: UK, England

Posted: 14th Jul 2016 13:49 Edited at: 14th Jul 2016 13:50

Link

Quote: "before you were executing playsprite() every frame so it was always setting the animation to the first frame. you need a system where by playsprite is executed ONLY when the state changes"

Further to the above suggestion provided by blink0k, in its simplest form, you could do this...

if GetSpritePlaying(spr) = 0 Then PlaySprite(spr)

Using AppGameKit V2 Tier 1

Back to top

Profile PM Email

Artformer

14

Years of Service

User Offline

Joined: 23rd Aug 2010

Location: Scotland

Posted: 14th Jul 2016 15:20

Link

Ah, I see... then I have to say that AGK2 documentation is incomplete, to say the least! Thanks folks!
