Keep a 3d object facing its linear velocity direction

Author

Message

RotaMafia

7

Years of Service

User Offline

Joined: 13th Oct 2017

Location: Portveien 2, Norway

Posted: 6th Feb 2022 02:33

Link

Hi again all

Sorry if this gets too frequent but i had such a good experience last time when asking a question, that I choose to get in touch again.
I now need a function to always rotate a object to it's line of travel.
i am creating in a 3d world and using physics by setting linear velocity.
All is really going good, but i can't figure out how to use "SetObject3DPhysicsAngularVelocity".
As the objects can collide and move around it must update and rotate accordingly to its line of travel.
Please help me get the angular velocity correct and finally get these boids moving smoothly.
I am a novice in coding, all tips and tricks are more then welcome ! c",)

/////////////////////////////////////////////////
//  Spesial thanks to:
// 	Daniel, "TheCodingTrain" - Youtube.
// 	Virtual Nomad & PartTimeCoder - Agk forum.
/////////////////////////////////////////////////
//  Boids for App Game Kit by RotaMafia

// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "boids" )
SetWindowSize( 1024, 768, 0 )
SetWindowAllowResize( 1 ) // allow the user to resize the window

// set display properties
SetVirtualResolution( 1024, 768 ) // doesn't have to match the window
SetOrientationAllowed( 1, 1, 1, 1 ) // allow both portrait and landscape on mobile devices
SetSyncRate( 30, 0 ) // 30fps instead of 60 to save battery
SetScissor( 0,0,0,0 ) // use the maximum available screen space, no black borders
UseNewDefaultFonts( 1 )

// blue fog
SetFogMode(1)
SetFogColor(0,50,200)
SetFogRange(150,1000)
SetSunActive(1)
SetAmbientColor(0,20,100)

// 3d world setup
Create3DPhysicsWorld()
//setphysicsdebugon()
Set3DPhysicsGravity(0.0, 0.0, 0.0)

// fibonacci sphere
#constant pi =  3.14159
#constant sequence# = 25 // sequence 25 for good spreadout (can be anything)

// camera setup
global camx
global camy
global camangx
global camangy

global camx#
global camy#
global camz#

SetCameraPosition(1,0,100,-200)
SetCameraLookAt  ( 1, 0 ,0 ,0,0)

// max number of boids
global maxboids = 100 // defult: 100

// display dream motion
global disp = 0 // attached not visible

// variables to multiplie with
global alignmentforce as float
global cohersionforce as float
global separationforce as float
global borderforce as float

// boids stats
global dim attached [ maxboids ]
global dim boid [ maxboids ] as boids
type boids

	//objects ref name
    object as integer
    state as integer
	velocity as float

    //next position
	boidsxvelocity as float
	boidsyvelocity as float
	boidszvelocity as float

//cohersion
    grp_cohersionx as float
	grp_cohersiony as float
	grp_cohersionz as float
	cohersionx as float
	cohersiony as float
	cohersionz as float
	grp_cohersiondist as float
	grp_cohersioncount as float

     //alignment
	grp_alignmentx as float
	grp_alignmenty as float
	grp_alignmentz as float
	alignmentx as float
	alignmenty as float
	alignmentz as float
	grp_alignmentdist as float
	grp_alignmentcount as float

	// separation
	grp_separationx as float
	grp_separationy as float
	grp_separationz as float
	separationx as float
	separationy as float
	separationz as float
	grp_separationdist as float
	grp_separationcount as float

	// borders
	borderx as float
	bordery as float
	borderz as float
	borderdist as float

endtype

// senses & intelligence
global spheresize as float
global viewrange as float
global separationrange as float
global maxlinearvelocity as float
global travledistance as float

spheresize 			= 50  					// start sphere size 							defult: 50
viewrange 			= 20					// range of each boids view						defult: 20
separationrange 	= viewrange				// separation detection range					defult: 20
maxlinearvelocity 	= 30					// boids max velocity aka speed					defult: 30
travledistance 		= 90					// set how far boids can travle from center 	defult: 90

// create boids in a sphere formation
_createboids()

// loop
do
	// run function for all boids
	for i = 1 to maxboids
		_cohersion(i)
		_alignment(i)
		_separation(i)
		_borders(i)
		_adjustment(i)
		_calculaterute(i)
		_calculatespeed(i)
		_move(i)
		_reset(i)
	next i

	// move cam function
	_movecam()

	// game world update
	Step3DPhysicsWorld()
	print("Fps  "+str(ScreenFPS(),1))
    Sync()
loop

// cohersion
function _cohersion(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_cohersiondist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_cohersiondist < viewrange and boid[selected].grp_cohersioncount < maxboids //and boid[selected].grp_cohersiondist > separationrange
				inc boid[selected].grp_cohersionx , GetobjectWorldX( boid[i].object )-GetobjectWorldX( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3X( boid[selected].currvec3 )-boid[i].boidsxvelocity  )
				inc boid[selected].grp_cohersiony , GetobjectWorldY( boid[i].object )-GetobjectWorldY( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3Y( boid[selected].currvec3 )-boid[i].boidsyvelocity  )
				inc boid[selected].grp_cohersionz , GetobjectWorldZ( boid[i].object )-GetobjectWorldZ( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3Z( boid[selected].currvec3 )-boid[i].boidszvelocity  )
				boid[selected].grp_cohersioncount = boid[selected].grp_cohersioncount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_cohersioncount > 0.0
		inc boid[selected].cohersionx 	, boid[selected].grp_cohersionx / boid[selected].grp_cohersioncount
		inc boid[selected].cohersiony 	, boid[selected].grp_cohersiony / boid[selected].grp_cohersioncount
		inc boid[selected].cohersionz 	, boid[selected].grp_cohersionz / boid[selected].grp_cohersioncount
    endif
endfunction

// alignment
function _alignment(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_alignmentdist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_alignmentdist < viewrange and boid[selected].grp_alignmentcount < maxboids
				inc boid[selected].grp_alignmentx , GetObject3DPhysicsLinearVelocityX(boid[i].object)
				inc boid[selected].grp_alignmenty , GetObject3DPhysicsLinearVelocityY(boid[i].object)
				inc boid[selected].grp_alignmentz , GetObject3DPhysicsLinearVelocityZ(boid[i].object)
				boid[selected].grp_alignmentcount = boid[selected].grp_alignmentcount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_alignmentcount > 0.0
		inc boid[selected].alignmentx 	, boid[selected].grp_alignmentx / boid[selected].grp_alignmentcount
		inc boid[selected].alignmenty 	, boid[selected].grp_alignmenty / boid[selected].grp_alignmentcount
		inc boid[selected].alignmentz 	, boid[selected].grp_alignmentz / boid[selected].grp_alignmentcount
	endif
endfunction

// separation
function _separation(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_separationdist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_separationdist < separationrange and boid[selected].grp_separationcount < maxboids
				inc boid[selected].grp_separationx ,GetObjectWorldX( boid[selected].object )-GetObjectWorldX( boid[i].object ) / boid[selected].grp_separationdist
				inc boid[selected].grp_separationy ,GetObjectWorldY( boid[selected].object )-GetObjectWorldY( boid[i].object ) / boid[selected].grp_separationdist
				inc boid[selected].grp_separationz ,GetObjectWorldZ( boid[selected].object )-GetObjectWorldZ( boid[i].object ) / boid[selected].grp_separationdist
				boid[selected].grp_separationcount = boid[selected].grp_separationcount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_separationcount > 0.0
		inc boid[selected].separationx , boid[selected].grp_separationx / boid[selected].grp_separationcount
		inc boid[selected].separationy , boid[selected].grp_separationy / boid[selected].grp_separationcount
		inc boid[selected].separationz , boid[selected].grp_separationz / boid[selected].grp_separationcount
	endif
endfunction

// borders
function _borders(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].borderdist = distance3D(0,0,0,GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object))
			if boid[selected].borderdist > travledistance
				inc boid[selected].borderx , (GetObject3DPhysicsLinearVelocityX(boid[selected].object) * boid[selected].velocity) - GetobjectWorldX(boid[selected].object)
				inc boid[selected].bordery , (GetObject3DPhysicsLinearVelocityY(boid[selected].object) * boid[selected].velocity) - GetobjectWorldY(boid[selected].object)
				inc boid[selected].borderz , (GetObject3DPhysicsLinearVelocityZ(boid[selected].object) * boid[selected].velocity) - GetobjectWorldZ(boid[selected].object)
			endif
		endif
	next i
endfunction

function _adjustment(selected as integer)

// force multiplier adjustment
	alignmentforce 	= 1.0
    cohersionforce 	= 1.0
    separationforce = 1.0
    borderforce 	= 1.0

	// cohersion
	boid[selected].cohersionx = boid[selected].cohersionx * cohersionforce
	boid[selected].cohersiony = boid[selected].cohersiony * cohersionforce
	boid[selected].cohersionz = boid[selected].cohersionz * cohersionforce

	// alignment
	boid[selected].alignmentx = boid[selected].alignmentx * alignmentforce
	boid[selected].alignmenty = boid[selected].alignmenty * alignmentforce
	boid[selected].alignmentz = boid[selected].alignmentz * alignmentforce

	// separation
	boid[selected].separationx = boid[selected].separationx * separationforce
	boid[selected].separationy = boid[selected].separationy * separationforce
	boid[selected].separationz = boid[selected].separationz * separationforce

	// borders
 	boid[selected].borderx = boid[selected].borderx * borderforce
 	boid[selected].bordery = boid[selected].bordery * borderforce
   	boid[selected].borderz = boid[selected].borderz * borderforce

endfunction

// calculate rute
function _calculaterute(selected as integer)

	// include all velocitys
	inc boid[selected].boidsxvelocity , ( GetObject3DPhysicsLinearVelocityX(boid[selected].object) + boid[selected].separationx + boid[selected].cohersionx + boid[selected].alignmentx + boid[selected].borderx )
	inc boid[selected].boidsyvelocity , ( GetObject3DPhysicsLinearVelocityY(boid[selected].object) + boid[selected].separationy + boid[selected].cohersiony + boid[selected].alignmenty + boid[selected].bordery )
	inc boid[selected].boidszvelocity , ( GetObject3DPhysicsLinearVelocityZ(boid[selected].object) + boid[selected].separationz + boid[selected].cohersionz + boid[selected].alignmentz + boid[selected].borderz )

endfunction

// calculate speed
function _calculatespeed(selected as integer)

	// calculate speed
    boid[selected].velocity = distance3D(boid[selected].boidsxvelocity,boid[selected].boidsyvelocity,boid[selected].boidszvelocity,GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object))
    if boid[selected].velocity < 5 then boid[selected].velocity = 5
    if boid[selected].velocity > maxlinearvelocity*2 then boid[selected].velocity=maxlinearvelocity

endfunction

// move calculate rute & calculate speed
function _move (selected as integer)
	// set new velocity
	SetObject3DPhysicsLinearVelocity( boid[selected].object,boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity , boid[selected].velocity )

	// keep steady (so the fixed disp object don't look too weird)
	SetObject3DPhysicsAngularVelocity( boid[selected].object,boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity , 0 )     `<- please help me figure out how to make them rotate with it's line of direction :)

	// rotate attached object
	if disp = 1
		SetObjectLookAt(attached[selected],boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity, 0 )
	endif
endfunction

// reste all states
function _reset(selected as integer)

// new move point
    boid[selected].boidsxvelocity = 0
	boid[selected].boidsyvelocity = 0
	boid[selected].boidszvelocity = 0

	// cohersion
	boid[selected].grp_cohersionx  = 0
	boid[selected].grp_cohersiony  = 0
	boid[selected].grp_cohersionz  = 0

	boid[selected].cohersionx  = 0
	boid[selected].cohersiony  = 0
	boid[selected].cohersionz  = 0

boid[selected].grp_cohersioncount = 0
	boid[selected].grp_cohersiondist  = 0

// alignment
	boid[selected].grp_alignmentx = 0
	boid[selected].grp_alignmenty = 0
	boid[selected].grp_alignmentz = 0

boid[selected].alignmentx = 0
	boid[selected].alignmenty = 0
	boid[selected].alignmentz = 0

boid[selected].grp_alignmentdist  = 0
	boid[selected].grp_alignmentcount = 0

//separation
	boid[selected].grp_separationx = 0
	boid[selected].grp_separationy = 0
	boid[selected].grp_separationz = 0

boid[selected].separationx = 0
	boid[selected].separationy = 0
	boid[selected].separationz = 0

boid[selected].grp_separationdist  = 0
	boid[selected].grp_separationcount = 0

	// borders
	boid[selected].borderx = 0
	boid[selected].bordery = 0
	boid[selected].borderz = 0

boid[selected].borderdist = 0
endfunction

// create boids in a sphere formation
function _createboids()
	for i = 1 to maxboids

		// calculate sphere position foreache boid
	    y# = 1.0 - (i/(maxboids-1.0)) * 2.0
	    radius# = SQRT(1-y#*y#)
	    theta# = pi * sequence# * i
	    y# = y# * spheresize
	    x# = SIN(theta#) * radius# * spheresize
	    z# = COS(theta#) * radius# * spheresize
	    // Psst: this is also great for creating points around
	    // the boids. Then create raycast between the boid and
	    // created points. This way you can "let the boid see!".
	    // With this the boid will avoid obsticals.
	    // I have a working function for this if you can't get
	    // it working. Just didn't include it.

	    // create and place
	    boid[i].object = createobjectbox(1,2,4)
		SetObjectPosition(boid[i].object, x#, y#, z# )

		// create and attach object to rotate
		attached[i] = createobjectbox(1,2,4)
		SetObjectColor(attached[i],0,25,25,255)
		SetObjectColor(attached[i],random(20,255),random(20,255),random(20,255),255)
		FixObjectToObject(attached[i],boid[i].object)
		SetObjectVisible(attached[i],0)
		SetObjectFogMode(attached[i],1)

		// set physic settings
		Create3DPhysicsDynamicBody( boid[i].object )
		SetObject3DPhysicsCanSleep( boid[i].object, 0 )
		SetObject3DPhysicsMass( boid[i].object, 0.5 )
		SetObjectCollisionMode( boid[i].object, 0 )
		SetObject3DPhysicsMaxLinearVelocity( boid[i].object, maxlinearvelocity )
		SetObject3DPhysicsLinearVelocity( boid[i].object,0-GetobjectWorldX( boid[i].object ) ,0-GetobjectWorldY( boid[i].object ) ,0-GetobjectWorldZ( boid[i].object ) ,maxlinearvelocity )
		SetObjectVisible(boid[i].object,1)
		SetObjectFogMode(boid[i].object,1)

	next i
endfunction

// move camera function
Function _movecam()

	// cam controls
	camspeed = 5 // cam speed
	if disp = 0 then print("Move camera with W,S,A,D,Q,E")
	if ( GetRawKeyState( 87 ) ) then MoveCameraLocalZ( 1,  camspeed )
	if ( GetRawKeyState( 83 ) ) then MoveCameraLocalZ( 1, -camspeed )
	if ( GetRawKeyState( 68 ) ) then MoveCameraLocalX( 1,  camspeed )
	if ( GetRawKeyState( 65 ) ) then MoveCameraLocalX( 1, -camspeed )
	if ( GetRawKeyState( 69 ) ) then MoveCameraLocalY( 1,  camspeed )
	if ( GetRawKeyState( 81 ) ) then MoveCameraLocalY( 1, -camspeed )

  	// decrese or increse max linear velocity
  	if disp = 0 then print("Press PLUSS or MINUS to adjust max linear velocity")
	if ( GetRawKeyState( 107 ) )
		maxlinearvelocity = maxlinearvelocity + 0.5
		print(maxlinearvelocity)
	elseif ( GetRawKeyState( 109 ) )
		if maxlinearvelocity > 1
			maxlinearvelocity = maxlinearvelocity - 0.5
			print(maxlinearvelocity)
		endif
	endif

	// display dream motion
	if disp = 0 then print("Press SPACE to see dream motion")
	if ( GetRawKeyPressed( 32 ) ) and disp = 0
		for i = 1 to maxboids
			SetObjectVisible(boid[i].object,0)
			SetObjectVisible(attached[i],1)
		next i
		disp = 1
  	elseif ( GetRawKeyPressed( 32 ) ) and disp = 1
		for i = 1 to maxboids
			SetObjectVisible(boid[i].object,1)
			SetObjectVisible(attached[i],0)
		next i
		disp = 0
  	endif

// rotate the camera w/mouse
	if disp = 0 then print("Hold any MOUSE BUTTON to move camera")
	if ( GetRawMouseLeftPressed() or GetRawMouseRightPressed() )
	    camx = GetPointerX()
	    camy = GetPointerY()
	    camangx = GetCameraAngleX(1)
	    camangy = GetCameraAngleY(1)
	endif

	if ( GetRawMouseLeftState() = 1 or GetRawMouseRightState() = 1)
	    camv1 = (GetPointerX() - camx)/camspeed
	    camv2 = (GetPointerY() - camy)/camspeed

	    camv3 = camangx + camv2
	    if ( camv3 > 89 ) then camv3 = 89
	    if ( camv3 < -89 ) then camv3 = -89
	    SetCameraRotation( 1, camv3, camangy + camv1, 0 )
	endif

endfunction

// distance tool from GameCreators forum library
function distance3D(x1#,y1#,z1#,x2#,y2#,z2#)
	dx#=x1#-x2#
	dy#=y1#-y2#
	dz#=z1#-z2#
	distance#=sqrt(dx#*dx#+dy#*dy#+dz#*dz#)
endfunction distance#

+ Code Snippet


/////////////////////////////////////////////////
//  Spesial thanks to:
// 	Daniel, "TheCodingTrain" - Youtube.
// 	Virtual Nomad & PartTimeCoder - Agk forum.
/////////////////////////////////////////////////
//  Boids for App Game Kit by RotaMafia


// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "boids" )
SetWindowSize( 1024, 768, 0 )
SetWindowAllowResize( 1 ) // allow the user to resize the window

// set display properties
SetVirtualResolution( 1024, 768 ) // doesn't have to match the window
SetOrientationAllowed( 1, 1, 1, 1 ) // allow both portrait and landscape on mobile devices
SetSyncRate( 30, 0 ) // 30fps instead of 60 to save battery
SetScissor( 0,0,0,0 ) // use the maximum available screen space, no black borders
UseNewDefaultFonts( 1 )

// blue fog
SetFogMode(1)
SetFogColor(0,50,200)
SetFogRange(150,1000)
SetSunActive(1)
SetAmbientColor(0,20,100)

// 3d world setup
Create3DPhysicsWorld()
//setphysicsdebugon()
Set3DPhysicsGravity(0.0, 0.0, 0.0)

// fibonacci sphere
#constant pi =  3.14159
#constant sequence# = 25 // sequence 25 for good spreadout (can be anything)

// camera setup
global camx
global camy
global camangx
global camangy

global camx#
global camy#
global camz#

SetCameraPosition(1,0,100,-200)
SetCameraLookAt  ( 1, 0 ,0 ,0,0)

// max number of boids
global maxboids = 100 // defult: 100

// display dream motion
global disp = 0 // attached not visible

// variables to multiplie with
global alignmentforce as float
global cohersionforce as float
global separationforce as float
global borderforce as float

// boids stats
global dim attached [ maxboids ]
global dim boid [ maxboids ] as boids
type boids

	//objects ref name
    object as integer
    state as integer
	velocity as float

    //next position
	boidsxvelocity as float
	boidsyvelocity as float
	boidszvelocity as float

	//cohersion
    grp_cohersionx as float
	grp_cohersiony as float
	grp_cohersionz as float
	cohersionx as float
	cohersiony as float
	cohersionz as float
	grp_cohersiondist as float
	grp_cohersioncount as float

     //alignment
	grp_alignmentx as float
	grp_alignmenty as float
	grp_alignmentz as float
	alignmentx as float
	alignmenty as float
	alignmentz as float
	grp_alignmentdist as float
	grp_alignmentcount as float

	// separation
	grp_separationx as float
	grp_separationy as float
	grp_separationz as float
	separationx as float
	separationy as float
	separationz as float
	grp_separationdist as float
	grp_separationcount as float

	// borders
	borderx as float
	bordery as float
	borderz as float
	borderdist as float

endtype

// senses & intelligence
global spheresize as float
global viewrange as float
global separationrange as float
global maxlinearvelocity as float
global travledistance as float

spheresize 			= 50  					// start sphere size 							defult: 50
viewrange 			= 20					// range of each boids view						defult: 20
separationrange 	= viewrange				// separation detection range					defult: 20
maxlinearvelocity 	= 30					// boids max velocity aka speed					defult: 30
travledistance 		= 90					// set how far boids can travle from center 	defult: 90

// create boids in a sphere formation
_createboids()

// loop
do
	// run function for all boids
	for i = 1 to maxboids
		_cohersion(i)
		_alignment(i)
		_separation(i)
		_borders(i)
		_adjustment(i)
		_calculaterute(i)
		_calculatespeed(i)
		_move(i)
		_reset(i)
	next i

	// move cam function
	_movecam()

	// game world update
	Step3DPhysicsWorld()
	print("Fps  "+str(ScreenFPS(),1))
    Sync()
loop

// cohersion
function _cohersion(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_cohersiondist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_cohersiondist < viewrange and boid[selected].grp_cohersioncount < maxboids //and boid[selected].grp_cohersiondist > separationrange
				inc boid[selected].grp_cohersionx , GetobjectWorldX( boid[i].object )-GetobjectWorldX( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3X( boid[selected].currvec3 )-boid[i].boidsxvelocity  )
				inc boid[selected].grp_cohersiony , GetobjectWorldY( boid[i].object )-GetobjectWorldY( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3Y( boid[selected].currvec3 )-boid[i].boidsyvelocity  )
				inc boid[selected].grp_cohersionz , GetobjectWorldZ( boid[i].object )-GetobjectWorldZ( boid[selected].object ) // / boid[selected].grp_cohersiondist //(GetVector3Z( boid[selected].currvec3 )-boid[i].boidszvelocity  )
				boid[selected].grp_cohersioncount = boid[selected].grp_cohersioncount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_cohersioncount > 0.0
		inc boid[selected].cohersionx 	, boid[selected].grp_cohersionx / boid[selected].grp_cohersioncount
		inc boid[selected].cohersiony 	, boid[selected].grp_cohersiony / boid[selected].grp_cohersioncount
		inc boid[selected].cohersionz 	, boid[selected].grp_cohersionz / boid[selected].grp_cohersioncount
    endif
endfunction

// alignment
function _alignment(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_alignmentdist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_alignmentdist < viewrange and boid[selected].grp_alignmentcount < maxboids
				inc boid[selected].grp_alignmentx , GetObject3DPhysicsLinearVelocityX(boid[i].object)
				inc boid[selected].grp_alignmenty , GetObject3DPhysicsLinearVelocityY(boid[i].object)
				inc boid[selected].grp_alignmentz , GetObject3DPhysicsLinearVelocityZ(boid[i].object)
				boid[selected].grp_alignmentcount = boid[selected].grp_alignmentcount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_alignmentcount > 0.0
		inc boid[selected].alignmentx 	, boid[selected].grp_alignmentx / boid[selected].grp_alignmentcount
		inc boid[selected].alignmenty 	, boid[selected].grp_alignmenty / boid[selected].grp_alignmentcount
		inc boid[selected].alignmentz 	, boid[selected].grp_alignmentz / boid[selected].grp_alignmentcount
	endif
endfunction

// separation
function _separation(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].grp_separationdist = distance3D(GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object),GetobjectWorldX(boid[i].object),GetobjectWorldY(boid[i].object),GetobjectWorldZ(boid[i].object))
			if boid[selected].grp_separationdist < separationrange and boid[selected].grp_separationcount < maxboids
				inc boid[selected].grp_separationx ,GetObjectWorldX( boid[selected].object )-GetObjectWorldX( boid[i].object ) / boid[selected].grp_separationdist
				inc boid[selected].grp_separationy ,GetObjectWorldY( boid[selected].object )-GetObjectWorldY( boid[i].object ) / boid[selected].grp_separationdist
				inc boid[selected].grp_separationz ,GetObjectWorldZ( boid[selected].object )-GetObjectWorldZ( boid[i].object ) / boid[selected].grp_separationdist
				boid[selected].grp_separationcount = boid[selected].grp_separationcount + 1.0
			endif
		endif
	next i

	// add up all
	if boid[selected].grp_separationcount > 0.0
		inc boid[selected].separationx , boid[selected].grp_separationx / boid[selected].grp_separationcount
		inc boid[selected].separationy , boid[selected].grp_separationy / boid[selected].grp_separationcount
		inc boid[selected].separationz , boid[selected].grp_separationz / boid[selected].grp_separationcount
	endif
endfunction


// borders
function _borders(selected as integer)
	for i = 1 to maxboids
		if i <> selected
			boid[selected].borderdist = distance3D(0,0,0,GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object))
			if boid[selected].borderdist > travledistance
				inc boid[selected].borderx , (GetObject3DPhysicsLinearVelocityX(boid[selected].object) * boid[selected].velocity) - GetobjectWorldX(boid[selected].object)
				inc boid[selected].bordery , (GetObject3DPhysicsLinearVelocityY(boid[selected].object) * boid[selected].velocity) - GetobjectWorldY(boid[selected].object)
				inc boid[selected].borderz , (GetObject3DPhysicsLinearVelocityZ(boid[selected].object) * boid[selected].velocity) - GetobjectWorldZ(boid[selected].object)
			endif
		endif
	next i
endfunction


function _adjustment(selected as integer)

	// force multiplier adjustment
	alignmentforce 	= 1.0
    cohersionforce 	= 1.0
    separationforce = 1.0
    borderforce 	= 1.0

	// cohersion
	boid[selected].cohersionx = boid[selected].cohersionx * cohersionforce
	boid[selected].cohersiony = boid[selected].cohersiony * cohersionforce
	boid[selected].cohersionz = boid[selected].cohersionz * cohersionforce

	// alignment
	boid[selected].alignmentx = boid[selected].alignmentx * alignmentforce
	boid[selected].alignmenty = boid[selected].alignmenty * alignmentforce
	boid[selected].alignmentz = boid[selected].alignmentz * alignmentforce

	// separation
	boid[selected].separationx = boid[selected].separationx * separationforce
	boid[selected].separationy = boid[selected].separationy * separationforce
	boid[selected].separationz = boid[selected].separationz * separationforce

	// borders
 	boid[selected].borderx = boid[selected].borderx * borderforce
 	boid[selected].bordery = boid[selected].bordery * borderforce
   	boid[selected].borderz = boid[selected].borderz * borderforce

endfunction

// calculate rute
function _calculaterute(selected as integer)

	// include all velocitys
	inc boid[selected].boidsxvelocity , ( GetObject3DPhysicsLinearVelocityX(boid[selected].object) + boid[selected].separationx + boid[selected].cohersionx + boid[selected].alignmentx + boid[selected].borderx )
	inc boid[selected].boidsyvelocity , ( GetObject3DPhysicsLinearVelocityY(boid[selected].object) + boid[selected].separationy + boid[selected].cohersiony + boid[selected].alignmenty + boid[selected].bordery )
	inc boid[selected].boidszvelocity , ( GetObject3DPhysicsLinearVelocityZ(boid[selected].object) + boid[selected].separationz + boid[selected].cohersionz + boid[selected].alignmentz + boid[selected].borderz )

endfunction

// calculate speed
function _calculatespeed(selected as integer)

	// calculate speed
    boid[selected].velocity = distance3D(boid[selected].boidsxvelocity,boid[selected].boidsyvelocity,boid[selected].boidszvelocity,GetobjectWorldX(boid[selected].object),GetobjectWorldY(boid[selected].object),GetobjectWorldZ(boid[selected].object))
    if boid[selected].velocity < 5 then boid[selected].velocity = 5
    if boid[selected].velocity > maxlinearvelocity*2 then boid[selected].velocity=maxlinearvelocity

endfunction

// move calculate rute & calculate speed
function _move (selected as integer)
	// set new velocity
	SetObject3DPhysicsLinearVelocity( boid[selected].object,boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity , boid[selected].velocity )

	// keep steady (so the fixed disp object don't look too weird)
	SetObject3DPhysicsAngularVelocity( boid[selected].object,boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity , 0 )     `<- please help me figure out how to make them rotate with it's line of direction :)

	// rotate attached object
	if disp = 1
		SetObjectLookAt(attached[selected],boid[selected].boidsxvelocity , boid[selected].boidsyvelocity , boid[selected].boidszvelocity, 0 )
	endif
endfunction

// reste all states
function _reset(selected as integer)

	// new move point
    boid[selected].boidsxvelocity = 0
	boid[selected].boidsyvelocity = 0
	boid[selected].boidszvelocity = 0

	// cohersion
	boid[selected].grp_cohersionx  = 0
	boid[selected].grp_cohersiony  = 0
	boid[selected].grp_cohersionz  = 0

	boid[selected].cohersionx  = 0
	boid[selected].cohersiony  = 0
	boid[selected].cohersionz  = 0

	boid[selected].grp_cohersioncount = 0
	boid[selected].grp_cohersiondist  = 0

	// alignment
	boid[selected].grp_alignmentx = 0
	boid[selected].grp_alignmenty = 0
	boid[selected].grp_alignmentz = 0

	boid[selected].alignmentx = 0
	boid[selected].alignmenty = 0
	boid[selected].alignmentz = 0

	boid[selected].grp_alignmentdist  = 0
	boid[selected].grp_alignmentcount = 0

	//separation
	boid[selected].grp_separationx = 0
	boid[selected].grp_separationy = 0
	boid[selected].grp_separationz = 0

	boid[selected].separationx = 0
	boid[selected].separationy = 0
	boid[selected].separationz = 0

	boid[selected].grp_separationdist  = 0
	boid[selected].grp_separationcount = 0

	// borders
	boid[selected].borderx = 0
	boid[selected].bordery = 0
	boid[selected].borderz = 0

	boid[selected].borderdist = 0
endfunction

// create boids in a sphere formation
function _createboids()
	for i = 1 to maxboids

		// calculate sphere position foreache boid
	    y# = 1.0 - (i/(maxboids-1.0)) * 2.0
	    radius# = SQRT(1-y#*y#)
	    theta# = pi * sequence# * i
	    y# = y# * spheresize
	    x# = SIN(theta#) * radius# * spheresize
	    z# = COS(theta#) * radius# * spheresize
	    // Psst: this is also great for creating points around
	    // the boids. Then create raycast between the boid and
	    // created points. This way you can "let the boid see!".
	    // With this the boid will avoid obsticals.
	    // I have a working function for this if you can't get
	    // it working. Just didn't include it.

	    // create and place
	    boid[i].object = createobjectbox(1,2,4)
		SetObjectPosition(boid[i].object, x#, y#, z# )

		// create and attach object to rotate
		attached[i] = createobjectbox(1,2,4)
		SetObjectColor(attached[i],0,25,25,255)
		SetObjectColor(attached[i],random(20,255),random(20,255),random(20,255),255)
		FixObjectToObject(attached[i],boid[i].object)
		SetObjectVisible(attached[i],0)
		SetObjectFogMode(attached[i],1)

		// set physic settings
		Create3DPhysicsDynamicBody( boid[i].object )
		SetObject3DPhysicsCanSleep( boid[i].object, 0 )
		SetObject3DPhysicsMass( boid[i].object, 0.5 )
		SetObjectCollisionMode( boid[i].object, 0 )
		SetObject3DPhysicsMaxLinearVelocity( boid[i].object, maxlinearvelocity )
		SetObject3DPhysicsLinearVelocity( boid[i].object,0-GetobjectWorldX( boid[i].object ) ,0-GetobjectWorldY( boid[i].object ) ,0-GetobjectWorldZ( boid[i].object ) ,maxlinearvelocity )
		SetObjectVisible(boid[i].object,1)
		SetObjectFogMode(boid[i].object,1)

	next i
endfunction

// move camera function
Function _movecam()

	// cam controls
	camspeed = 5 // cam speed
	if disp = 0 then print("Move camera with W,S,A,D,Q,E")
	if ( GetRawKeyState( 87 ) ) then MoveCameraLocalZ( 1,  camspeed )
	if ( GetRawKeyState( 83 ) ) then MoveCameraLocalZ( 1, -camspeed )
	if ( GetRawKeyState( 68 ) ) then MoveCameraLocalX( 1,  camspeed )
	if ( GetRawKeyState( 65 ) ) then MoveCameraLocalX( 1, -camspeed )
	if ( GetRawKeyState( 69 ) ) then MoveCameraLocalY( 1,  camspeed )
	if ( GetRawKeyState( 81 ) ) then MoveCameraLocalY( 1, -camspeed )

  	// decrese or increse max linear velocity
  	if disp = 0 then print("Press PLUSS or MINUS to adjust max linear velocity")
	if ( GetRawKeyState( 107 ) )
		maxlinearvelocity = maxlinearvelocity + 0.5
		print(maxlinearvelocity)
	elseif ( GetRawKeyState( 109 ) )
		if maxlinearvelocity > 1
			maxlinearvelocity = maxlinearvelocity - 0.5
			print(maxlinearvelocity)
		endif
	endif

	// display dream motion
	if disp = 0 then print("Press SPACE to see dream motion")
	if ( GetRawKeyPressed( 32 ) ) and disp = 0
		for i = 1 to maxboids
			SetObjectVisible(boid[i].object,0)
			SetObjectVisible(attached[i],1)
		next i
		disp = 1
  	elseif ( GetRawKeyPressed( 32 ) ) and disp = 1
		for i = 1 to maxboids
			SetObjectVisible(boid[i].object,1)
			SetObjectVisible(attached[i],0)
		next i
		disp = 0
  	endif

	// rotate the camera w/mouse
	if disp = 0 then print("Hold any MOUSE BUTTON to move camera")
	if ( GetRawMouseLeftPressed() or GetRawMouseRightPressed() )
	    camx = GetPointerX()
	    camy = GetPointerY()
	    camangx = GetCameraAngleX(1)
	    camangy = GetCameraAngleY(1)
	endif

	if ( GetRawMouseLeftState() = 1 or GetRawMouseRightState() = 1)
	    camv1 = (GetPointerX() - camx)/camspeed
	    camv2 = (GetPointerY() - camy)/camspeed

	    camv3 = camangx + camv2
	    if ( camv3 > 89 ) then camv3 = 89
	    if ( camv3 < -89 ) then camv3 = -89
	    SetCameraRotation( 1, camv3, camangy + camv1, 0 )
	endif

endfunction

// distance tool from GameCreators forum library
function distance3D(x1#,y1#,z1#,x2#,y2#,z2#)
	dx#=x1#-x2#
	dy#=y1#-y2#
	dz#=z1#-z2#
	distance#=sqrt(dx#*dx#+dy#*dy#+dz#*dz#)
endfunction distance#

P.S. Made out of several tutorials on YouTube. Especially Daniel's tutorials at "The Coding Train".
But this is all my code. Feel free to explore and use as you wish and maybe you can figure it out

"I, for one love finding stuff like this. Let us share the fun"

Attachments

Login to view attachments

Back to top

Profile PM

Virtual Nomad

Moderator

18

Years of Service

User Offline

Joined: 14th Dec 2005

Location: SF Bay Area, USA

Posted: 6th Feb 2022 05:58

Link

you want the objects to gradually rotate to face their direction of travel as in this demo, right?

just making sure before i dive into another rabbit hole

AGK Tower Defense Community Competition | [TD]
AGK Resource Directory
AGK on Itch.io
TGC @ GitHub
Some Snippets

Back to top

Profile PM Website

RotaMafia

7

Years of Service

User Offline

Joined: 13th Oct 2017

Location: Portveien 2, Norway

Posted: 6th Feb 2022 07:23

Link

Hi again @VirtualNomad

Yes that's exactly what I want. Kind of like a plane, fish or homing missile would be turning.
I have looked all over the forum, and the "push create" and "moving car" threads seem to be touching in on it.
But i can't figure it out

Its looks to be a hot topic on several threads usually ending with a "lookat" solution, but it feels kind of sad to leave it like this.
Being so close to perfect and all

Back to top

Profile PM

OriginalKronos

7

Years of Service

User Offline

Joined: 10th Nov 2017

Location:

Posted: 9th Feb 2022 00:06 Edited at: 9th Feb 2022 00:22

Link

--deleted-- Thought I'd done something clever then spotted you had already done it in the code...

Is not pressing the spacebar giving you the effect you wanted..They look pretty fishy.

I would add you could probably do with some spatial partitioning to efficiently calculate nearest boid neighbours as currently you are cycling through roughly 40000+ boids every loop which I think is why your demo is slow.

Back to top

Profile PM

OriginalKronos

7

Years of Service

User Offline

Joined: 10th Nov 2017

Location:

Posted: 9th Feb 2022 00:15 Edited at: 9th Feb 2022 00:47

Link

Can't really tell if this is an improvement or not to be honest but try deletiing the fixobjecttoobject in line 384 and replace line 300 with

+ Code Snippet

SetObjectPosition(attached[selected],getobjectWorldX(boid[selected].object),getobjectWorldY(boid[selected].object),getobjectWorldZ(boid[selected].object))
SetObjectLookAt(attached[selected],getObjectWorldX(boid[selected].object)+boid[selected].boidsxvelocity , getObjectWorldY(boid[selected].object)+boid[selected].boidsyvelocity , getObjectWorldZ(boid[selected].object)+boid[selected].boidszvelocity, 0 )

only works for the coloured fish after pressing space. Movement seems a little less erratic but I could be wrong.

Back to top

Profile PM

RotaMafia

7

Years of Service

User Offline

Joined: 13th Oct 2017

Location: Portveien 2, Norway

Posted: 9th Feb 2022 04:04 Edited at: 9th Feb 2022 04:33

Link

Hi @OriginalKronos

They're pretty fishy but the problem is that thay do not "turn around".
Ex. i have made a test with food. when thay get close thay can do 180*degree with
no motion between the two positions.

What i am looking for is a solution to have them turn around gradually.
But i can't get it working. Hope to use: "SetObject3DPhysicsAngularVelocity".
Don't really understand how "SetObject3DPhysicsAngularVelocity" works. I have tried with
several approaches but nothing works. Sounds so easy.
"Just turn gradually based on the attached objects angle, or boids next vector position."
Feel like i am doing somthing wrong. Really appreciate any help on this!.

Hope to improve on the boid code as i go, but stuck on this for now.
The "display by pushing space" was just meant as a reference.
I use it to se effect of "SetObject3DPhysicsAngularVelocity" as
i test diffrent approaches :p

Thanks for your input OriginalKronos
really enjoy this forum

Back to top

Profile PM

jd_zoo

6

Years of Service

User Offline

Joined: 12th May 2018

Location: Nova Scotia

Posted: 11th Feb 2022 01:20

Link

This looks awesome well done!

Back to top

Profile PM Email Website

Sorry your browser is not supported!

Newcomers AppGameKit Corner / Keep a 3d object facing its linear velocity direction

Attachments
